Cov khoom no siv hydrogen roj cell raws li lub zog system. Lub hydrogen nyob rau hauv lub siab siab carbon fiber hydrogen cia lub raj mis yog input rau lub fais reactor los ntawm lub integrated valve ntawm decompression thiab siab tswj. Nyob rau hauv hluav taws xob reactor, hydrogen reacts nrog oxygen thiab converts nws mus rau hauv hluav taws xob zog. Piv nrog rau cov tsheb roj teeb rov qab, nws cov txiaj ntsig zoo tshaj plaws yog lub sijhawm luv roj puv sijhawm thiab kev ua haujlwm ntev (txog 2-3 teev nyob ntawm qhov ntim ntawm hydrogen cia lub raj mis). Cov khoom no yog dav siv nyob rau hauv lub nroog sib koom tsheb, takeout tsheb, tsev neeg scooter thiab hais txog.
| Lub npe: Hydrogen powered ob lub log
| Tus Qauv Zauv: JRD-L300W24V
| ||
| Technical parameter qeb | Reactor technical parameters | DCDC technical reference | Rnpau taws |
| Rated zog (w) | 367 ib | 1500 | + 22% |
| Rated voltage (V) | 24 | 48 | -3%～8% |
| Rated tam sim no (A) | 15.3 | 0-35 | +18% |
| Kev ua tau zoo (%) | 0 | 98.9 ua | ≥53 |
| Cov pa purity (%) | 99.999 ib | ≥99.99 (CO <1 ppm) | |
| Hydrogen siab (πpa) | 0.06 ib | 0.045 ~ 0.06 hli | |
| Cov pa oxygen (ml / min) | 3.9 | +18% | |
| Kev khiav hauj lwm qhov kub thiab txias (° C) | 29 | -5-35 | |
| Kev khiav hauj lwm qhov kub thiab txias (RH%) | 60 | 10～95 | |
| Cia ambient kub (° C) | -10～50 | ||
| Suab nrov (db) | ≤ 60 | ||
| Reactor loj (mm) | 153 * 100 * 128 hli | Qhov hnyav (kg) | 1.51 ib |
| Reactor + Tswj qhov loj (mm) | 415 * 320 * 200 hli | Qhov hnyav (kg) | 7.5 |
| Cia ntim (L) | 1.5 | Qhov hnyav (kg) | 1.1 |
| Lub tsheb loj (mm) | 1800 * 700 * 1000 hli | Tag nrho qhov hnyav (kg) | 65 |
Tuam txhab Profile
VET Technology Co., Ltd yog lub tuam txhab hluav taws xob ntawm VET Group, uas yog lub teb chaws high-tech enterprise tshwj xeeb hauv kev tshawb fawb thiab kev tsim kho, tsim khoom, muag thiab kev pabcuam ntawm tsheb thiab lub zog tshiab, feem ntau yog kev lag luam hauv lub cev muaj zog, lub tshuab nqus tsev twj, roj cell & ntws roj teeb, thiab lwm yam khoom siv tshiab.
Ntau xyoo dhau los, peb tau sib sau ua ke ib pab pawg neeg paub txog kev lag luam thiab cov txuj ci tshiab thiab R & D pab pawg, thiab muaj kev paub zoo hauv cov khoom tsim thiab kev siv engineering. Peb tau ua tiav tsis tu ncua kev ua tiav tshiab hauv cov khoom tsim cov txheej txheem cov khoom siv automation thiab semi-automated ntau lawm kab tsim, uas ua rau peb lub tuam txhab muaj kev sib tw muaj zog hauv kev lag luam tib yam.
Nrog R & D muaj peev xwm los ntawm cov ntaub ntawv tseem ceeb mus rau qhov kawg cov khoom siv, cov thev naus laus zis thiab cov thev naus laus zis tseem ceeb ntawm kev ywj pheej cov cuab yeej cuab tam tau ua tiav ntau qhov kev tshawb fawb thiab thev naus laus zis tshiab. Los ntawm kev tsim txiaj ntawm cov khoom lag luam ruaj khov, qhov zoo tshaj plaws tus nqi tsim qauv thiab cov kev pabcuam zoo tom qab muag, peb tau txais kev lees paub thiab kev ntseeg siab los ntawm peb cov neeg siv khoom.
